| Product Type |
LED TV |
| TV System |
PAL ; NTSC ; SECAM |
| Receiving Range |
48.25MHz - 863.25 MHz |
| No of Channel (ATV) |
200 |
| Power Supply |
AC 110V-240V 50/60Hz |
| Power Consumption (TV On) |
75W |
| Power Consumption (STB) |
< 0.5 W |
| Hardware Configuration : |
| CPU |
Quad Core ARM Cortex |
| GPU |
Multi Core Mali |
| CPU Frequency |
1.1 GHz |
| GPU Frequency |
470 MHz |
| DDR RAM Size |
1GB |
| eMMC Flash |
8 GB |
| Software Configuration : |
| OS |
Android 9.0 (Android TV) |
| Google Play Store |
Yes |
| Screen Mirroring |
Chromecast |
| Wifi Hotspot |
Yes |
| YouTube |
Yes |
| Netflix |
Yes |
| Amazon Prime |
Yes |
| HDMI (CEC,ARC) |
Yes |
| Panel Specification : |
| Backlight Unit |
DLED |
| Aspect Ratio |
16:9 |
| Panel Size |
1.09m |
| Display Resolution |
1920 X 1080 |
| Brightness |
300 ± 10 cd/m2 (typical) |
| Contrast Ratio |
1200:1 (typical) |
| Response Time |
8 ms (typical) |
| Viewing Angle |
178° / 178° |
| Color |
Black |
| Refresh Rate |
60 Hz |
| Sound : |
| Audio Power Output |
2 X 8 Watt |
| Sound Mode |
Standard, Music, Theater, News, User |
| Sound Control |
2 Ch Speaker System |
| Surround Sound |
Yes |
| Terminals : |
| Bottom Terminals: |
| RJ45 (LAN Port) |
1 |
| COAX Out |
1 |
| HDMI In |
3 |
| AV In |
1 |
| AUDIO Out ( 3.5 mm) |
1 |
| Side Terminals: |
| RF In |
1 |
| USB 2.0 |
2 |
| Mini YPbYr |
1 |
| Device Media Format : |
| Music |
MP3; WAV |
| Picture |
JPG/JPEG/BMP/PNG |
| Video |
AVI; MP4; TS/TRP; MPG; MOV; DAT; VOB; RM/RMVB |
| Text |
TXT |
| Subtitle |
SRT; .SUB; .SMI |
| Dimensions & Weight : |
| TV with Stand (L × W × H) |
963.25 mm × 236.29 mm × 617.55 mm |
| TV without Stand (L × W × H) |
963.25 mm × 90 mm × 569.55 mm |
| TV Shipping dimensions (L × W × H) |
1090 mm × 172 mm × 700 mm |
| TV with Stand Weight |
7.76 KG |
| TV without Stand Weight |
7.62 KG |
| TV Shipping Weight |
11.02 ± 0.5 KG |
| Loading : |
| 40 HQ Container |
Approx. 414 Pcs |
| 40 GP Container |
Approx. 414 Pcs |
| 20 GP Container |
Approx. 201 Pcs |
